Auto Tension Gravure Printing Machine High Speed With Magnetic Powder
Quick Detail:
Max speed: 100-120m/min
Diameter of roll material: 800mm (normal)
Plate Material: resin plate or rubber
Color& page: Multi-color printing press
Anilox roller:steel or ceramic anilox
Tension: Auto tension controller
Application: Flexible Packaging Printing
Certificate: CE Certificate
Description:
1. Unwind unit: Magnetic powder with auto. tension, EPC device
2. Rewind unit: Magnetic powder with auto. tension
3. Machine is run with helical gear
4. Anilox roller is from Japan Murata brand
5. Easy operation, flexible starting, accurate color register.
6.The meter counter can set printing quantity according to the requirements.
7. Automatically at the quantity or when the material is cut off.
8. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting
9. The printing ink is spread by the anilox cylinder with even ink color.
10. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Suitable material:
Kraft Paper: 40 ~ 350g/m2, Single-sided Coated Paper: 30 ~ 350g/m2,
Copy Paper: 15 ~ 350g/m2, Firecrackers and Paper: 40 ~ 350g/m2,
Paper Money and Incense: 25 ~ 350g/m2, Silicone Paper: 50 ~ 350g/m2,
Coated Paper: 30 ~ 350g/m2, Dust-free Paper: 25 ~ 350g/m2,
Release Paper: 40 ~ 350g/m2, Composite Paper: 30 ~ 350g/m2,
Non-woven: 15-120 grams, Woven: 15-500 g, PVC: 10 ~ 120μ M,
OPP: 10 ~ 100μ M, BOPP: 10 ~ 100μ M, PE: 15 ~ 150μ M,
NY: 10 ~ 120μ M, PET: 10 ~ 100μ M, CPP: 10 ~ 100μ M
Specification:
Model: |
YT-B4600 |
Max Width of Material |
600mm |
Max. Width of Printing: |
560mm |
Material: |
PVC:15~120μm,OPP:10~100μm,BOPP:10~100μm, |
Printing color: |
4 colors |
Max. Length of Printing |
280-1100mm |
Machinery mechanical speed |
10-120m/min |
Max. Speed of Material Printing |
10-100m/min |
Thickness of Plate |
2.28mm |
machine weight |
400mKg |
machine dimension |
4500*1800*2500mm |
Power |
Voltage:380V,3PH,50HZ |
2)Unwind Unit |
|
Max. Length of Roller |
650mm |
Max. Width of Material |
600mm |
Max. Dia. of Unwind |
¢1000mm |
Type of Unwind |
Auto Tension with Magnetic Powder |
Unwind Magnetism device |
5kg |
Auto Tension Controller Unwind |
2-20kg |
Unwind EPC |
Electrical Edge Correction Device |
Feeding shaft |
Air shaft |
Axis core diameter¢ |
76mm |
3)Traction Unit |
|
Constitution of Traction |
Aluminum roller, Chrome plated Roller |
Traction Zones |
3 Zones |
4)Printing Unit |
|
Constitution of Printing |
Ceramic Anilox Roller with doctor blade . |
Girth of Pressing Roller |
One set of 400mm standard for free |
Material of Plate |
Resin or Rubber |
Principle of Work |
Helical Gears with Timing Belt Drive |
Adjusting of Register |
Manual |
Overprint Precision(mm) |
Horizontal:+-0.15mm,Vertical:+-0.15mm |
Plated-glued roller adjusting |
Hydraulic type of plate-cylinder |
Anilox Roller |
Ceramic Anilox Roller:1pcs/per color |
Rubber rollers |
1pcs/per color |
Doctor Blade |
1pcs/per color |
5)Heating and Drying Unit |
|
Type of Heating and drying |
Blowing first then heating |
Heating Zones |
7 zones |
Power of Heating |
10.5kw |
Assistance of Drying Length |
0.6m*2 |
Blowers |
14pcs |
Power of Blowers |
35w*1pcs |
6)Electrical Parts |
|
Main motor |
3.7kw |
Ink-Transfer Motor |
15w*4pcs |
The inverter |
3.7kw (An Inverter Equips With the Main Motor) |
Tension test |
2--20kg |
7)Rewind Unit |
|
Max Width of Roller |
650mm |
Max Width of Material |
600mm |
Max. Dia. of Rewind |
¢1000mm |
Type of Rewind |
Magnetic powder with auto. tension |
The receiving shaft |
Air shaft |
Axis core diameter |
¢76mm |
